is spelled J/105 but J105, J 105 and J-105 spellings are also found.
The boat has been sold.
2001 J105 Sailboat Chantecler
Check the boat's Major Features.
This is an example of what you can do with it:
2002 BOR
Want some Details?
The Arrival in Baltimore. The J/105's Interior.
See More Sailing with
Chantecler. Want to see More Deck pictures? Want
to see More Details pictures?
One of the big advantage of the J/105 is the
discussion forum
of the
web site.
Discussions there are often rich learning experiences, thanks to
contributors such as Andy Skibo. One J/Boats dealer once was not pleased
with the unbiased and frank discussions of the J/105 strengths and
weaknesses. He saw this best practice in knowledge management as a threat to
his bottom line. Fortunately his attempt to tone it down has failed and the
forum has thrived together with the J/105 fleet.
I have peppered this web site with old forum discussions. Here is a discussion on
the offshore capabilities of the J/105. This discussion is on
pulling the mast forward on a run. This one
is on gybes. Discussion on
the mainsheet system.
|
Former ad on the
web site:
Hull #536 (June 2001) is a J/Europe-built Deep Draft wheel
J/105, which is also better for cruising (sleeps 5) because it was initially
equipped for offshore and distance racing. Boat raced J/105 OD class in the
Chesapeake Bay. Silver 2002 Annapolis-Bermuda.
|
|
|
"This boat has no bad
habits"
John Driver (former owner of J/105 #163
Thoosa)
The J/105 caught my eye when I crewed on Alizé, a C&C
40, racing PHRF A2 in the Chesapeake Bay along several of the early
J/105s. They looked elegant, fast and needed only about half the 11
people we needed to get Alizé competitive. When, in 1979, I started
looking for a sailboat to buy after many years of leasing and a few
years of racing, I naturally turned to a few J/105s owners and emailed
them. I got several enthusiastic responses and the one that sticks to my
mind to this day is the one above. John had bought Thoosa in New England
and he was talking about the offshore delivery from there, made mostly
under asymmetric spinnaker. I still had fresh in my mind a couple of bad
rolling broaches we have had with Alizé
that spring racing season and how uneasy some of us felt when running
under spinnaker in heavy air at night for the Solomon's race.
Another outstanding response from a J/105 owner was from
John Kircher who was looking for a boat partner and I soon became a
J/105 co-owner on #208 Jay Boat.
From my experience with both Jay Boat and Chantecler, I
can say that John Driver was right on, the boat has no bad habits. => |
I have, from time to time, sailed in nasty weather,
most notably the 2001 race to
Baltimore, the 2002 Bermuda race and
back, the 2003
return from Screwpile and the
2004 race to Oxford
(18+ kn of boat speed under reefed main only). I have destroyed two
spinnakers (during the
2002 BOR practice and BOR
return). I have had a few broaches. But when we followed the proper
safe procedures I have never felt that the boat was out of control.
When pushing the envelope, broaches are difficult to
totally prevent in unstable weather. As a helmsman I have felt the loss
of steerage, but in many cases I was able to regain control after I
learned the trick of shacking the wheel back-and-forth rapidly. This
stops the flow that feeds air into the gap between the rudder and its
boundary layer that had become detached, reattaches it and reestablishes
steerage and directional control. If that does not work, the team should
in that order, ease the spinsheet to reduce the sideways force, ease the
vang to spill air at the top of the main and ease the mainsheet and
these measures are likely to stop the broach. In order to do that, there
should be a constant dialogue between the helmsperson and the spinnaker
trimmer. They should constantly communicate aloud what they feel and the
rest of the team should be listening. The team has to learn not to
overdo the corrective measures, as we lost our two spinnakers in the next step
after an initial broach when the boat straightens up after slowing down
and a more powerful wind flow is suddenly reestablished on the spinnaker
and the next thing we heard was the bang of the spinnaker torn up a few
inches outside the reinforcement at the tack.
At mark roundings, hoisting
the asymmetric spinnaker from the fore hatch is easy.
Gibing is also
relatively easy. Dousing in heavy air could be more difficult if one
does not have the possibility to run deep to spill air from the
spinnaker. But, with proper technique,
this task can be mastered even by good but unexceptional or shorthanded
crew. |
|
|
J-105
The J/105 is
another example of J-Boats’ proven philosophy that simple, well
conceived, and solidly constructed boats will succeed. After more than
10 years in production and 600 boats, this remains one of the company’s
most popular models.
Following the
J/105’s introduction in late 1991, Sailing World magazine (January 2004)
chose it as its “Boat of the Year” in the Racer/Cruiser category,
although with 5’ 5” inches of headroom in the main cabin and rather
limited accommodations, I don’t think this boat fits any reasonable
person’s definition of a 34-foot cruiser. It’s not strictly a racer
either, because it clearly has appeal beyond the race course, and
“daysailer” is much too narrow of definition. So, what do we call this
unique model? Let’s just say this is a multiple-purpose “fun boat” that
will appeal to sailors who place more importance on competitive
one-design racing and responsive performance than entertaining or
cruising on weekends.
The J/105 measures
34’ 6” (10.5 meters) length overall and waterline length is 29’ 5”.
Maximum beam is an even 11’, standard draft is 6’ 6” and the designed
displacement is 7,750 lbs with a 44% ballast-to-displacement ratio. A
shoal draft model offers 5’ 6” draft and a slightly higher ballast to
account for the raised center of gravity. The majority of J/105s built
are of the deep draft variety.
Tillotson Pearson
International (TPI) builds the J/105 utilizing the patented SCRIMP
process. Simply put, fiberglass materials and core materials are laid up
without any resin. The lay-up is then sealed in plastic and a vacuum
applied to remove all the air. Resin is then introduced and the vacuum
draws the resin through the composite. The process allows precise
control over resin to fiberglass ratios and results in a strong yet
lightweight hull. TPI pioneered resin infused composites and J/105s are
sold with a 10-year hull warranty that includes osmotic blistering.
The deck layout of
the J/105 is very clean, yet another benefit of a simple design. There
is a 20” square forward hatch which, if not already modified, will need
a means to prevent the hatch from opening past 180 degrees which causes
the frame to crack. The T-shaped cockpit is very large and separated by
the mainsheet traveler which is within easy reach of the helm. Standard
equipment is a tiller with a Spinlock hiking stick, although a 42-inch
Edson wheel is offered as an option. The reversed transom has a molded
cavity and swim ladder for easy boarding. |
The cabin
accommodations are spartan yet functional and easily maintained. There
is a seven-foot-long V-berth forward by a port head and starboard
hanging locker. Aft of the main bulkhead there is a small galley to
starboard and navigation table to port followed by port and starboard 6’
6”-long settee/berths. The icebox is a 54-quart portable cooler that
fits beneath the companionway steps.
Auxiliary power is
provided by a 20-hp inboard Yanmar diesel and a Martec folding
propeller.
For a boat with a sail area-to-displacement ratio of 24, the J/105 is
remarkably easy to sail, even shorthanded. In fact, the only complaint I
have heard about the sailing characteristics of the J/105 is her
performance to windward in light air. Some have added an overlapping
genoa to help in this regard, but these are not allowed by one-design
racing rules which limit the sail inventory to a mainsail,
non-overlapping jib and an asymmetrical spinnaker.
Once the wind
picks up to over 8 knots this boat shines on all points of sail, and by
all reports, is downright exciting reaching and running in moderate to
heavy air. Sustained speeds of 12 to 13 knots broad reaching in 20 knots
of wind are not uncommon and the well-balanced hull form, low center of
gravity and large rudder allow the boat to be sailed under control in
these conditions. Gone are the days of white-knuckle downwind runs and
death rolls.
The current
published value ranges from $55,700 for a 1992 model to $151,500 for a
2004 model. Of the 18 models I found currently offered for sale, the
least expensive was a 1992 model for $85,000 and the most expensive a
2004 model for $149,500. Records of six J/105s sold over the last 12
months ranged from $88,300 for a 1996 model to $132,500 for a 2004
model. This suggests that used J/105 models are holding their value very
well and that the published prices are likely a bit below the market for
older models and a bit optimistic on newer models.
While I think the
J/105 could be a great daysailer, her strength clearly lies in her
appeal as a one-design racer. There is a very strong class association
and J/105 fleets are now in nearly all major sailing centers across the
country. For
big boat racing enthusiasts, it’s hard to beat a boat that offers great
competition with a crew of two to six people when it may take eight to
10 people to crew a comparably sized handicapped racer. |
| The first page
of my J/105 subweb |
| The major
features of J105 hull #536 |
|
Don't miss this important technical bulletin on rudder bearings,
companionway slider stop, hull to deck joint, mast tuning and mast
bend, engine stop cable, bowsprit seals, and battery specs |
| The second
launch of my J-105 in Baltimore, from shrink wrap and cradle to the
water |
| The anchor
well, the bow sprit seals, the gimbaled two-burner propane stove, the
three sea berths with lee clothes, the instruments, the sails and
other details of the J105 |
|
| The V-berth,
the mast step, the sinks, the navigation table, the stove area, and
other views from the interior of the J/105 |
| The J105
under sail, upwind with genoa and main |
| The J 105
wheel, instrument remote, propane bottle locker, the genoa tracks, the
triple cabin top rope clutches, the foot rest for the main trimmer,
and the cabin top instrument cluster |
| The
J/105 masthead, the Sparcraft mast, which permits masthead asymmetric
spinnakers and the forehatch. |
|
|
|
|
|
|
Chantecler logo
(design by Salima Bentchicou-Gonord,
Architecte DESA)
|
|
